Description
Flexibility of cooking zones
- 60 cm: space for 4 pots or pans.
- Cooking zone front left: 145 mm, 1.4 KW
- Cooking zone rear left: 180 mm, 1.8 KW (max. power 3.1 KW)
- Cooking zone rear right: 145 mm , 1.4 KW
- Cooking zone front right: 180 mm, 1.8 KW
- TouchSelect Basic: control the power with imprinted +/- touch buttons.
- Variable 9-stage power settings for each zone: precisely adapt the heat with 9 power levels.
- PowerBoost function in the front left zone
- : boil water faster thanks to 50% more energy than at the highest standard level.
- QuickStart function: when switching on, the hob automatically selects the cooking zone with cookware (when placed on a zone whilst the hob is off).
- Quick Stop: quickly switch off a cooking zone with one longer touch.
- Frameless design
- Control panel lock: prevent unintended activation of the hob.
- Main on/off switch: switch off all cooking zones at the touch of a button.
- Automatic safety shut off: for safety reasons, heating stops after a preset time if not used (possible to customise).
- Dimensions of the product (HxWxD mm): 51 x 592 x 522
- Required niche size for installation (HxWxD mm) : 51 x 560 x (490 - 500)
- Min. worktop thickness: 16 mm
- Connected load: 3.7 KW
- Power management options for 16A, 13A or 10A connection: limit the maximum power if needed (depends on fuse protection of electric installation).
- Power cord 1.1 m UK 3 pin plug: plug and play, no electrician required for installation.
- This hob is equipped with a UK 3 pin plug for an easy plug & play installation. The plug limits the maximum power output to 3.7 KW. For higher power output, please select a hob without plug and ensure installation is carried out by a qualified electrician.
Details
EAN: |
4242005285419 |
Brand Name: |
Bosch |
Features | Benefits: |
The Induction hob: Faster than gas and ceramic hobs, induction is easier to clean and more energy efficient. |
Feature: |
Plug & Play: plugs easily into the socket. |
Feature: |
PowerBoost: up to 50% more power for faster heating on your induction hob. |
Feature: |
QuickStart: start straight away and select the desired cooking level. |
Feature: |
The handy ChildLock locks the control panel to prevent accidental changes in settings. |
Feature: |
Induction: Fast, precise cooking, easy cleaning and low energy consumption. |
Type of Control | Appliances: |
Electronic |
Type of Control Settings: |
EasyTouch, front |
Construction Type: |
Built-In |
Installation Type: |
Built-In |
Safety Features: |
childproof lock, Power management function, Safety time-switch-off |
Energy Input: |
Electric |
Appliance Voltage (V): |
220-240 |
Appliance Frequency (Hz): |
50; 60 |
Approval Certificates: |
AENOR, CE |
Plug Type: |
GB plug |
Cooker | Oven Time Options: |
No delay options |
Type of Frame: |
Frameless |
Type of Regulation: |
Stepless energy regulated |
Type of Lid: |
Without |
Residual Heat Indicator Type: |
Separate |
Heating Element Type: |
Induction heating |
Heating Element Type 3: |
Induction heating |
Heating Element Type 7: |
Induction heating |
Heating Element Power: |
1.4 |
Heating Element Power 3: |
1.8 |
Heating Element Power 5: |
1.4 |
Heating Element Power 7: |
1.8 |
Heating Element Location: |
front left |
Heating Element Location 2: |
center left |
Heating Element Location 3: |
back left |
Heating Element Location 4: |
middle back |
Heating Element Location 5: |
back right |
Heating Element Location 6: |
center right |
Heating Element Location 7: |
front right |
Heating Element Location 8: |
front middle / central |
Heating Element Location 9: |
front centre/cent |
Automatic Programs: |
No |
Ignition System: |
No |
Main On | Off Switch: |
Yes |
Cooker | Over Automatic Programs: |
No |
Compartment Timer: |
No |
Power On Indicator: |
No |
Cord Length: |
110 Centimetre |
Min Niche Height: |
490 Millimetre |
Max Niche Height: |
500 Millimetre |
Min Niche Width: |
560 Millimetre |
Max Niche Width: |
560 Millimetre |
Niche Depth: |
51 Millimetre |
Heating Element Dimension: |
145 Millimetre |
Heating Element Dimension 3: |
180 Millimetre |
Heating Element Dimension 5: |
145 Millimetre |
Heating Element Dimension 7: |
180 Millimetre |
Country of Origin - Code: |
SPAIN |
Number of Gas Burners: |
0 |
Number of Electric Cooking Zones: |
4 |
Number of Electric Plates: |
0 |
Number of Radiant Plates: |
0 |
Number of Halogen Plates: |
0 |
Number of Induction Plates: |
4 |
Number of Electric Warming Zones: |
0 |
Height: |
51 |
Depth: |
522 |
Consumer Item - Gross Weight: |
11.3 |
Product Bullet: |
Plug & Play: plugs easily into the socket. |
Product Bullet 2: |
PowerBoost: up to 50% more power for faster heating on your induction hob. |
Product Bullet 3: |
QuickStart: start straight away and select the desired cooking level. |
Product Bullet 4: |
The handy ChildLock locks the control panel to prevent accidental changes in settings. |
Product Bullet 5: |
Induction: Fast, precise cooking, easy cleaning and low energy consumption. |
Consumer Item - Height: |
51 |
Consumer Item - Depth: |
522 |
Heating Element Type 5: |
Induction heating |
Hob Type: |
Induction |
Supplier SKU: |
PUG61RAA5B |
